Optical parameters
ZS7045 |
标配(无辅助物镜) |
带有辅助物镜 Auxiliary Lens |
||||||||||
0.3X |
0.5X |
0.75X |
1.5X |
2X |
||||||||
目镜 |
工作距离100mm |
工作距离287mm |
工作距离165mm |
工作距离117mm |
工作距离45mm |
工作距离30mm |
||||||
放大倍率 |
视场 |
放大倍率 |
视场 |
放大倍率 |
视场 |
放大倍率 |
视场 |
放大倍率 |
视场 |
放大倍率 |
视场 |
|
WF10X20mm |
7X |
28mm |
2.1X |
70.8mm |
3.5X |
52.1mm |
5.3X |
35.1mm |
10.5X |
19mm |
14X |
13.5mm |
45X |
4.3mm |
13.5X |
12.1mm |
22.5X |
8.4mm |
33.8X |
5.6mm |
67.5X |
3mm |
90X |
2.2mm |
|
WF15X15mm |
10.5X |
20.6mm |
3.2X |
55mm |
5.3X |
40.2mm |
7.9X |
27.6mm |
15.8X |
13.5mm |
21X |
10.2mm |
67.5X |
3.2mm |
20.3X |
10.2mm |
33.8X |
6.4mm |
50.6X |
4.3mm |
101.3X |
2.2mm |
135X |
1.7mm |
|
WF20X10mm |
14X |
13.1mm |
4.2X |
38.4mm |
7X |
26.9mm |
10.5X |
17.8mm |
21X |
9.5mm |
28X |
6.5mm |
90X |
2.1mm |
27X |
6.3mm |
45X |
4.3mm |
67.5X |
2.9mm |
135X |
1.5mm |
180X |
0.8mm |
|
WF25X9mm |
17.5X |
14.5mm |
5.3X |
40.7mm |
8.8X |
30mm |
13.1X |
19.2mm |
26.2X |
8.5mm |
35X |
7.1mm |
112.5X |
2.2mm |
33.8X |
6.3mm |
56.3X |
4.3mm |
84.4X |
3.1mm |
168.8X |
1.2mm |
225X |
1mm |
|
WF30X8mm |
21X |
11.1mm |
6.3X |
32.4mm |
10.5X |
22.8mm |
15.8X |
15mm |
31.5X |
7.5mm |
42X |
5.3mm |
135X |
1.9mm |
40.5X |
5mm |
67.5X |
3.5mm |
101.3X |
2.3mm |
202.5X |
1.2mm |
270X |
0.9mm |
Specification
观察头 |
45°倾斜,360°旋转,瞳距54---76mm;双边视度调节±5屈光度 |
铰链式双目 Hinged binocular |
|
目镜 |
标准配置:WF10X20,高眼点广角型目镜,为佩戴眼镜的观察者提供方便 |
可选目镜 |
WF10X20mm,WF15X15mm,WF20X10mm,WF25X9mm,WF30X8mm |
放大倍数 |
标准配置:7X---45X,选配目镜和辅助物镜可扩展至2.1X---270X,连续变倍 |
物镜 |
0.7X---4.5X连续变倍,物镜变倍比1:6.4,确保像面齐焦性 |
辅助物镜 |
0.3X,0.5X,0.7X,1X,1.5X,2X可选配 For option |
工作距离 |
100mm
|
调焦托架 |
内径76mm,立柱孔径32mm |
底座 |
STL3底板式滑轨支架(标配),可配选其他底座,详见底座系列图 |
照明 |
可选配各种LED环形灯,详见LED光源系列图 |
工作平台 |
黑白工作板 |
