TS30

目镜  Eyepiece

WF10X

WF20X

物镜放大倍数
Objective
magnification

放大倍数
Magnification

视场
view

放大倍数
Magnification

视场
view

工作距离
Working Distance

1X

10X

20mm

20X

10mm

56mm

2X

20X

10mm

40X

5mm

57mm

3X

30X

6.7mm

60X

3.3mm

61mm

4X

40X

5mm

80X

2.5mm

58mm

放大倍数
Magnification

10X---40X

目镜
Eyepiece

标准配置：WF10X   Standard WF10X

可选目镜
Optional eyepiece

WF10X，WF20X

观察头
Observation head

360°旋转，45°倾斜枪管；单边视度调节±5屈光度
360°rotative，45°inclined barrel;Unilateral diopter adjustment±5

双目观察头  Binocular observation head

瞳距
Interpupillary distance

54mm---76mm

物镜

Objective

1X，2X，3X，4X  旋转式360° 360°Rotated

看台

Stand

垂直移动的齿轮齿条，固定手柄
Vertically mobile rack-and-pinion,fixing handle

工作距离
Working Distance

57mm

照明系统
Illumination

落射/透射光源  Incident/Transmitted Light

内置交流适配器，用于EPL照明和LED照明
Built-in AC adapter for epi-illumination and transmission LED illumination

工作平台

Plate

磨砂玻璃工作板  Glass plate

外型尺寸
Outward Size

115mm(W)X180mm(D)X220mm(H)
